| Working Width (mm) | 5-'1605, 6'-1870, 7'-2110, 8'-2360 |
|---|
| Type of Blade | L-Type |
|---|
| Overlap (mm) | 15 |
|---|
| Thickness of Blades (mm) | 7 |
|---|
| No. of Blades | 5'36 BL, 6'-42 BL, 7'-48 BL, 8'-54 BL |
|---|
| Total number of flange | 5'-6 flange, 6'-7 flange, 7'8 flange, 9'-9 flange |
|---|
| No. of Blades Per Flange | 6 Blades Per Flange |
|---|
| Outer Diameter of Rotor Shaft (mm) | 70 / 90 Diameter |
|---|
| Rotor Diameter (mm) | 430 |
|---|
| Side Drive | Gear Drive |
|---|
| Material of Blades | Boron |
|---|
| Safety Clutch (Shear Bolt) in PTO Shaft | Shear Bolt PTO Shaft |
|---|
| Rotavator Stand | Yes |
|---|
| Ground Over Propeller Shaft | Yes |
|---|
| Making / Labelling of Machine | Provider |
|---|
| Literature | Provider |
|---|
